Portable type Infrared Inspection Apparatus for Mammary Gland
1) Apparatus introduction
This apparatus is the perfect combination of computer digital technology, optics and
imageology. It uses infrared transmittance characteristic scanning and diagnosing
breast, which is the necessary equipment for medical department, health department
and Planned Parenthood Department.
2), Applicable Range:
Used for diagnosis and test for mastopathy, widely applicable in medical institution of
3), Working principle
The apparatus is based on the characteristics that hemoglobin has a clear selective
absorption of infrared radiation, using infrared light to scan the breast tissue. The
signal is processed after the photoelectric conversion by host computer. According to
the gray image, border, blood vessels distribution, it can determine whether the
tumour is malignant or benign and detect proliferative, inflammatory and cystic
lesions. It has great value for filtering breast cancer, survey of health women.
4) Apparatus features,
1) two-probe design, convenient to choose by the clinic need
2) quartz handle can stepless adjust, convenient to use, low heat, can be used
continually for a long time
3) Fiber probe can be set respectively with electrical source and lamphouse, with
small prods, leaky less, better anti-interference performance.
4) High-definition, 19-inch LCD, real-time dynamic color display
5) Imported high-resolution, low-light CCD camera
6) Using the latest version of the image processing software, perfect visibility,and high sensitivity
7) Perfect function of color image processing and case files editing
5) Software features:
1. Dynamic video recoding without time limit and storage system
2. Possessing functions of real-time, freezing, collecting, processing, pseudo-color,
measuring, comparing, saving, editing images and others.
3. Large C / S structure database server
4. Compatible with the PACS system, with a sound network system function
5. Editing report quickly and easily, and owning lots of practical expert diagnosis
thesaurus, templates, making it easy to tune out and edit.
6. With rich standard body parts map, typical case images and diagnostic results to
help doctors quickly and accurately diagnose the illness
7. More than 300,000 cases storage capacity
8. Connected with HIS to transmit patient’s information via the internet
6) Technical parameter,
(1) Resolution: ≥600TVL
(2) Grayscale: 256 levels
(3) Quality of picture catcher: 1024*768
(4) Images storage: ≥800.000 frames
(5) Lamp house: maximum illumination of 1 × 105LUX, continuously adjustable
(6) Continuous working time: ≥24hours
Packaging & Shipping
Our After-sale service:
Products sold by the company is guaranteed for 18 months. The company will send specialized staff for maintenance in 18 months once. If necessary, the company can provide circuit diagrams and component list. In the warranty period, failures caused by product quality, maintenance is free of charge. Beyond the guarantee, repair is for all of the life.
The following causes of failure are not in the scope of guarantee:
a) Unauthorized disassembly and modification.
b) Inadvertently tempering, or falling.
c) Lack of reasonable maintenance or environmental requirements.
d) The operation not in accordance with the requirements of this manual.
e) Without the permission of the company to repair.
f) Force majeure.
No guarantee for consumption and fragile goods.
No guarantee if unable to offer quality books of the company.
Please directly contact the agents, if purchasing equipment from the agents of the company.
